1. Total Pixels Number
NTSC: 1020(H) x 508(V) 520K
PAL: 1020(H) x 596(V) 610K
2. Effective Pixels Number
NTSC: 976(H) x 494(V) 480K
PAL: 976(H) x 582(V) 570K
3. Pick-up Device
1/3"960H EXview HAD CCD II (Sony)
4. Lens Fitted
Board,
5. Signal Process
Digital Signal Process
6. Scanning System
2: 1 Interlace
7. Sync System
Internal
8. Scanning Frequency
NTSC: 59.94Hz (VD)
PAL: 50Hz (VD)
9. Horizontal Resolution
700 TV Lines
10. S/N Ratio
More than 50dB (AGC Off )
11. Video Output
1.0Vpp composite (75R)
12. Min. Illumination
0.1Lux /30IRE, F2.0
13. Shutter Speed
NTSC: 1/60 ~ 1/100, 000 sec
PAL: 1/50 ~ 1/100, 000 sec
14. Power Consumption
DC12V, Max. 80mA
DC5V, Max. 150mA
15. Operating Temperature
-10C ~ 50C (Humidity: 0% RH ~ 80% RH)
16. Storage Temperature
-20C ~ 60C (Humidity: 0% RH ~ 85% RH)
17. Size: 25mm*25mm
18. OSD(Option)
SHUTTER: SHUT, SHUT+IRIS, IRIS /AGC: AGC: OFF, AGC
WHITE BALANCE: ATW, PUSH, USER1, USER2, ANTI CR, MANUAL, PUSH LOCK
BACKLIGHT: OFF, BLC, HLC
ATR: OFF, BLC, HLC
ATR: OFF, ON (Level adjustable)
NR: OFF, ON (Level adjustable)
DAYNIGHT: AUTO, COLOR, B/W
PICT ADJUST: MIRROR, BRIGHTNESS, CONTRAST, SHARPNESS, HUE, GAIN
MOTION DETECTION: OFF, ON (4 AREAS)
PRIVACY: OFF, ON (4 AREAS)
CAMERA ID: 0~9, A~Z, Special Character
