1.Total Pixels Number
1020(H) x 508(V) 520K(NTSC)
1020(H) x 596(V) 610K(PAL)
2.Effective Pixels Number
976(H) x 494(V) 480K(NTSC)
976(H) x 582(V) 570K(PAL)
3.Pick-up Device
1/3" 960H EXview HAD CCD II (Sony)
4.Lens Fitted
Board/Pinhole/Varifocal
5.Signal Process
Digital Signal Process
6.Scanning System
2:1 Interlace
7.Sync System
Internal
8.Scanning Frequency
59.94Hz (VD)(NTSC)
50Hz (VD)(PAL)
9.Horizontal Resolution
700 TV Lines
10.S/N Ratio
More than 50dB (AGC Off)
11.Video Output
1.0Vpp composite (75R)
12.Min. Illumination
0.1Lux/30IRE,F2.0
13.Shutter Speed
1/60 -1/100,000 sec(NTSC)
1/50 -1/100,000 sec(PAL)
14.Power Consumption
DC5V,150mA
15.Operating Temperature
-10C - 50C (Humidity 0% RH -80% RH)
16.Storage Temperature
-20C - 60C (Humidity 0% RH -85% RH)
17.OSD(Option)
1).LENS: MANUAL,DC
2).SHUTTER /AGC
   SHUTTER:SHUT,SHUT+IRIS,IRIS
   AGC: OFF, AGC
3).WHITE BALANCE
   ATW, PUSH, USER1, USER2, ANTI CR, MANUAL, PUSH LOCK
4).BACKLIGHT
   OFF, BLC, HLC
5).ATR
   OFF, ON (Level adjustable)
6).NR
   OFF, ON (Level adjustable)
7).DAYNIGHT
   AUTO, COLOR, B/W
8).PICT ADJUST
   MIRROR, BRIGHTNESS, CONTRAST, SHARPNESS, HUE, GAIN
9).MOTION DETECTION
   OFF, ON (4 AREAS)
10).UNKNOW
   OFF, ON (4 AREAS)
11).CAMERA ID
   0-9, A-Z, Special Character
